Products for Electrical Utilities
Products for Electrical Utilities
Single phase Energy Meter Box
DTC Metering Box
Street Light Metering Box
LT Box
Power Distribution Box
Suitable for DTC Metering Box Application for Distribution transformer centres and also for LT Tamper Proof Box, with Tamper Proof Arrangement, all weather, Box Made out of(FGRP)SMC
Sheet Mould Compound(SMC) which is a composite material with fiber reinforced polyester resin with suitable fillers
Features
Lower weight compered to Metal enclosures
High strength
No rusting – No maintenance
All Insulated Body – Shock Proof
All Weather – No deterioration of Cabinet – 100% weatherproof
Termite Proof
Cable Entry suitable for Sides as well as Bottom, Suitable for existing as well as new installations
Pole / Wallmounting arrangement
Anti Temper – with Hidden hinges and Good locking mechanisms
No Pilferage – Zero value in resale scrap market.
Size and Suitability
Dimension : 945*438*250mm
Suitable for Single Phase Energy meter installations
Optimam dimensions – Ease of maintenance in the field
Pole Mounting / Wall Mounting Fixtures supplied with Box
Scope of Supply
Fully Assembled DTC Metering Box, with Tamper Proof window, Hingns, Clamps, Current Transformers, with or Without Meters
Fully Assembled LT Tamper Proof box with Tamper Proof windows, Hinges, Clamps, Bus Bar assembly
Only assembled box, with Tamper proof windows, Hinges, Clamps
Certification
our boxes have been tested by NABL Laboratories for following
Fire retardant – Class FV-0 as per IS:11731 Part-2 or V-0 as per UL-94
High heat distortion temperature (200*C as per IS:10192)
SMC material as Per IS13410-1992
IP 54
Low Tension Distribution boxes are an electrical junction box enclosure housing electrical connection, to protect the connections and provide a safety barrier.
Low Tension Distribution boxes are made out to Sheet Mould Compound which is a composite material with fiber reinforced polyester resin with suitable fillers
Features
Lower weight compared to Matal enclosures
High strength
No rusting – No maintenance
All Insulated Body – Shock Proof
All Weather – No deterioration of Cabnet – 100% weatherproof
Termite Proof
Cable Entry from Transformer is well suited at the bottom
Pole mounting arrangement
Anti Tamper – with Hidden hings and Good locking mechanisms
No Pilferage – Zero value in resale scrap market.
Scope of Supply
Only Bare SMC Box
Supply with complete assembly with busbar, MCCB, etc
Size and Suitability
Dimensions : 1000*840*250
Suitable for Transformers from 100 KVA to 250 KVA
Optimum dimensions – Ease of maintainance in the field
Pole Mounting Fixtures supplied with Box
Certification
Our boxes have been tested by NABL laboratories for following
Fire retardant – Class FV-0 as per IS:11731 Part-2 or V-0 as per UL-94
High heat distortion temperature (200*C as per IS:10192)
Marking – IS 14772
Dimensions as per IS14772
Aerial Fuse boards are used on the Pole, between the service mains and UG cable for LT distribution.
These boards are integrated unit consisting of a moulded base of various sizes and fuse carriers Made of SMC, which makes it all weather, Shock proof, Vandal Proof.
Sheet Mould Compound (SMC) which is a composite material with is a composite material with fiber reinforced polyester resin with suitable fillers
Features
Pole moutable , suitable for all kinds of Poles used in the Distribution side Integrated parts, Ease and safe to installation and Easy Maintenace
All the Live holes are sealed with Epoxy Compound.
FGRP Fuse Boards are Maintenance free, rust proof and shock proof.
Excellent D-electric strength, No power leakage.
Safe tried & Tested method.
Mounting arrangements of Fuse Board on Pole with clamps.
Fire resistant, Excellent weather ability No decay and Long life
Withstands coastal / polluted atmosphere, UVradiation and Monsoon resistant.
Lower Field Complaint
Safe for human insulated body
Vandal proof
Prevents illegal Tapping
Long life
Certification
Our FUSES have been tested by NABL laboratories for following
Fire retardant – Class FV-0 as per IS:11731 Part-2 or V-0 as per UL-94
High heat distortion temperature (200*C as per IS:10192)
Dimensions as per IS14772
Supply Scope
Fully assembled Boards with cutouts and pole fixing clamps
Ranges and Ratings
| 10-22 Amps. | 1 Way Out-out FGRP Aerial Fuse Board. |
| 30 Amps. | 3 Way Out-out FGRP Aerial Fuse Board. |
| 30 Amps. | 4 Way Out-out FGRP Aerial Fuse Board. |
| 30 Amps. | 5 Way Out-out FGRP Aerial Fuse Board. |
| 30 Amps. | 6 Way Out-out FGRP Aerial Fuse Board. |
| 60 Amps. | 3 Way Out-out FGRP Aerial Fuse Board. |
Molded Gratings
FB – FRP Molded grating is manufactured in an open mold systems, Continues E-glass roving’s are placed is the mold in alternating layer and completely wetted out with resin. This continues process produce a integral, one piece construction which provided excellent corrosion resistance as well as bi-directional strength. There are number of different moulds available resulting in extensive range of panel sizes, thickness and mesh pattern
Features
Lower weight compared to Metal enclosures
High strength
No rusting – No maintenance
All Insulated Body – Shock Proof
All Weather – No deterioration of Canet – 100% weather prof
Termite Proof
Pole / Wallmounting arrangement
Anti tamper – with Hidden hinges and Good locking mechanism.
No Pilferage – Zero value in resale scrap market
Anti – Fire
Anti corrosion and anti aging
Anti slippery
Easy Installation with Various sizes and colours available
Functions
Anti-slip Floor, stair tread, Footbridge
Operation platform,trench cover
Security and safety fence,Handrall
Off-shore oil rig, shipyard, shipping deck, ceiling
Ramp ladder, scaffold,railways
Decorative grid, man-made fountain pool grid
Non-conductive and non-magnetic
Idustries
Chemical plant and metalfinishing
Construction engineering, traffic and transportation.
Petrochemical engineering, Ocean survey, water engineering
Food and beverage plants
Textile printing and dyeing and electronic industries
Size
| Thickness | Bridge width | Mesh space | Sizes |
|---|---|---|---|
| 25 | 6.5/5 | 50*50 | 1800*750 |
| 25 | 6.5/5 | 38*38 | 1800*750 |
